GF-8
The GF-8 is unique and unparalleled in relation of size and stability. This crane can be built as both a platform crane as a remote-crane. There are about 10 configurations possible.
The GF-8 offers a wide range of options and configurations that will certainly satisfy the demands of the modern film and video production.
SPECS
Max Payload (Head + Camera)
80 kg (176 lbs)
Max Length (Pivot to Front End)
10 m (35.37 ft)
Min Length (Pivot to Front End)
4 m (13.12 ft)
Rear Section Length (Pivot to Rear End)
2.52 m (8.3 ft)
Max Lens Height Overslung
10.54 m (34.58 ft)
Max Lens Height Underslung
10.54 m (34.58 ft)
Dolly Length
1.27 m (4.17 ft)
Dolly Width
0.83 m (2.72 ft)
Total Maximum Weight
1046 kg (2306.03 lbs)
Footprint 360° Length
6 m (19.69 ft)
Footprint 360° Width
6 m (19.69 ft)
Footprint 180° Length
6 m (19.69 ft)
Footprint 180° Width
3 m (9.84 ft)
Track Wheels
Yes
Track Size
620 mm (24.41 inch)
